The Adam Equipment GBC Bench Counting Scale is a durable, fully featured solution for industrial counting applications. With capacities from **35 lb to 130 lb** and graduations as fine as **0.001 lb**, the GBC ensures accurate results for inventory control, quality assurance, and production tasks. Its **stainless steel platform and die-cast aluminum base** are designed to withstand daily use in busy environments.
Equipped with a pillar-mounted ABS indicator and large backlit display, the GBC makes it easy to see unit weight, total weight, and piece count at a glance. Advanced counting functions, multiple connectivity options, and rechargeable battery power make it versatile for warehouses, production lines, and industrial workplaces.
- Capacities from 35 lb to 130 lb with graduations from 0.001 lb to 0.005 lb
- Backlit LCD displays unit weight, total weight, and count simultaneously
- Numeric keypad enables quick entry of unit weight and sample size
- Rugged die-cast aluminum base with stainless steel pan for durability
- RS-232 interface standard; optional USB port available
- Internal counting resolution 1:600,000 for high precision
- Color-coded keys for simple, fast operation
- Preset tare function speeds repetitive tasks
- Programmable audible alarms for overload and check counting
- Built-in rechargeable battery plus AC adaptor included
Technical Specifications
| Model |
GBC 35a |
GBC 70a |
GBC 130a |
| Maximum Capacity |
35 lb (16 kg) |
70 lb (32 kg) |
130 lb (59 kg) |
| Readability |
0.001 lb |
0.002 lb |
0.005 lb |
| Repeatability (S.D.) |
0.002 lb |
0.004 lb |
0.01 lb |
| Linearity (±) |
0.002 lb |
0.004 lb |
0.01 lb |
| Internal Counting Resolution |
1:600,000 |
1:600,000 |
1:600,000 |
| Pan Size |
11.8" × 15.7" (300 × 400 mm) |
11.8" × 15.7" (300 × 400 mm) |
11.8" × 15.7" (300 × 400 mm) |
| Stabilization Time |
2 seconds |
2 seconds |
2 seconds |
| Weighing Units |
lb, kg |
lb, kg |
lb, kg |
| Display |
Backlit LCD, 0.8" digits |
Backlit LCD, 0.8" digits |
Backlit LCD, 0.8" digits |
| Interface |
RS-232 standard; optional USB |
RS-232 standard; optional USB |
RS-232 standard; optional USB |
| Calibration |
External calibration |
External calibration |
External calibration |
| Power Supply |
12VDC 800mA adaptor; internal rechargeable battery |
12VDC 800mA adaptor; internal rechargeable battery |
12VDC 800mA adaptor; internal rechargeable battery |
| Operating Temperature |
14°F to 104°F (-10°C to 40°C) |
14°F to 104°F (-10°C to 40°C) |
14°F to 104°F (-10°C to 40°C) |
| Housing |
ABS indicator; die-cast aluminum base; stainless steel pan |
ABS indicator; die-cast aluminum base; stainless steel pan |
ABS indicator; die-cast aluminum base; stainless steel pan |
| Overall Dimensions |
11.8" × 20.5" × 26.8" (300 × 520 × 680 mm) |
11.8" × 20.5" × 26.8" (300 × 520 × 680 mm) |
11.8" × 20.5" × 26.8" (300 × 520 × 680 mm) |
| Net Weight |
16.8 lb (7.6 kg) |
16.8 lb (7.6 kg) |
16.8 lb (7.6 kg) |
| Applications |
Weighing, parts counting, check counting |
Weighing, parts counting, check counting |
Weighing, parts counting, check counting |
Add Ons
**Calibration certificate** Provides certified accuracy documentation
**USB port option (Type B)** Adds modern USB connectivity
**RS-232 cable 9M-9F** Legacy RS-232 connectivity option
**USB cable A-B** Required for USB integration
**In-use wet cover** Protects scale from contaminants and extends life
